Equipment calibration for Field-IQ 9 Field-IQ system setup
1.
At the Configuration screen, select Field-IQ and then tap Calibrate.
2. At the Field-IQ Calibration screen, select the Rate and Section Control Module to be calibrated.
(The message Not calibrated displays at the end of the modules that need calibration.) The Field-IQ
Calibration screen displays that includes the serial number of the rate and section control
module you just selected.
3. Select Flow Calibration. The Rate and Section Controller Valve Calibration screen displays.
4.
Select the Control tab and complete the settings for:
ll Allowable Error
l Gain
l MinimumResponse
Note – For information about the appropriate values for your sprayer, see the Support Note - Field-IQ
Crop Input Control System: For Sprayers and Spreaders.
5. Tap OK to return to the Field-IQ Calibration screen.
6. Select Flow Calibration. The Granular Calibration screen displays.
7.
At the Calibrate tab, complete the settings.
Setting Explanation
Gate Height Setting
Current height of the gate opening.
If you entered a gate height measurement during setup,
you must enter a measurement here.
Staff Encoder Constant
8. Tap Calculate to calibrate the constant. The Calibration Constant Calculator screen displays.
9.
Complete the settings.
Setting Explanation
Gate Width
Width of the gate opening
Drag Chain Distance Per Rev
The length of the drag chain per turn of the drag shaft.
To figure the drag chain length, you can either:
ll Multiply the diameter of the drag shaft by 3.14.
l Mark the belt and measure the distance the mark
moved after one revolution of the drag shaft.
If these numbers are not correct, you will have issues
calibrating the spreader. If any of these settings physically
change in the implement, they need to be adjusted in the
FM-1000 integrated display to maintain accuracy.
