Water Management functionality 18 Operations
Button Explanation
Delete Benchmark
Tap to remove any benchmark on the field that you have
selected.
You do not need to drive over a benchmark to delete it.
Logging
Tap to log coverage. This shows on the map where you have
been, dependent on your implement width. A shape file is
created with cut/fill and height information.
Auto
Engages automatic blade height control:
l Starts the slope calculation
l Resets the height
l Resets the cut/fill
Flat Plane (Laser) and Flat Plane (GPS) modes
When driving in Flat Plane mode, these options operate the same:
l Flat Plane (Laser): Use this model when the land has previously been leveled with a laser system
and you want to touch up the field. This model results in a mathematically flat surface (which
means the plane does not follow the curvature of the Earth, but completely flat).
l Flat Plane (GPS): Results in a design with a surface that is curved the same as the surface of the
Earth (an equipotential surface).
Note – Neither of these models can be used with a laser system. The entire FieldLevel II system only works
with GPS.
The controls on the Leveling panel for these modes are:
Button Explanation
Coarse
/
Fine
Coarse: The blade will move by large increments.
Fine:The blade will move by small increments.
Raises the blade by the fine or coarse increment.
Lowers the blade by the fine or coarse increment.
Design
Tap to open the Plane Editor. Here you can edit the design
plane.
Bench
or
Re-Bench
Tap to create a benchmark or re-bench.
Set the Design Height equal to the Blade Height.
Delete Benchmark
Removes any benchmark on the field. You do not need to
438 FM-1000 Integrated Display User Guide Version 9.25, Revision B
