Water Management functionality 18 Operations
Set survey height offset
To set the Survey Height Offset:
1. At the Home screen, tap . The Configuration screen displays.
2.
Select WM-Drain and tap Setup.
3. On the tile plow, raise the boot as high as it will raise.
4. Measure the distance from the bottom of the tile boot to the ground.
5.
Enter this value into the Survey Height Offset entry box.
Note – It is recommended that you change the survey point spacing to 1.5m (5 feet). This will then
record the survey points every 1.5M (5 feet) and provide a more accurate profile of the ground surface.
6. Tap OK.
454 FM-1000 Integrated Display User Guide Version 9.25, Revision B
