18 Operations Water Management functionality
Create a tile / ditch survey line
Before creating the survey line, Set survey height offset (page 454). This offset will be applied to the
heights of your surveyed alignment so that you do not need to rebench before installing tile.
1.
At the Run screen, tap to open the WM-Drain panel.
2. Go to the Survey tab of the panel.
3. Drive to a point that will be untouched to use as a reference point.
4.
Tap to create a master benchmark and flag this point so you can find it again easily.
5.
Drive the vehicle to the start of the line where you want to install tile or clean a ditch.
Note – For the most efficient method, it is recommended that you drive to the high end of the line.
6. From the Type list, select the type of design. The options are Main, Sub main and Lateral.
7. In the Size entry box, enter the size of the design.
8.
Tap Record Section to begin recording a section and then drive. To pause recording, tap Pause
Section. (The Record button changes to white when activated.)
If you have created a section you want to remove, tap Delete Section and choose the section
from the list that displays.
Note – For the most efficient method, it is recommended that the end point is where the tile line is to be
connected to a main or outlet.
9. To add a manual survey point at a distance different from the normal survey distance, tap
Manual Data Point.
10. Tap Record again to stop the recording.
11.
If you create a benchmark you want to remove, tap and choose the benchmark from the
list that displays.
