18 Operations Water Management functionality
Control Explanation
Height Offset Increase Raise the tile boot or blade by the
Slope Adjust
increment.
Height Offset
Decrease
Lower the tile boot or blade by the
Slope Adjust
increment.
Height Offset Increase Raise the boot or blade by the blade step increment.
Height Offset
Decrease
Lower the boot or blade by the blade step increment.
Slope Select a defined percentage of vertical drop for a horizontal distance
traveled.
Coarse (Height Offset) When you tap
Coarse
, the increase or decrease button moves the
blade by the
Coarse Blade
increment. This enables you to move the
blade by a larger increment.
Pitch Offset Increase Raises the blade pitch relative to the design pitch.
Pitch Offset Decrease Lowers the blade pitch relative to the design pitch.
Coarse (Pitch Offset) When you tap
Coarse
, the increase or decrease button moves the
blade by the
Coarse Pitch
increment. This enables you to move the
blade pitch by a larger increment.
Auto Set Automatics to the hydraulic valve. The blade or tile boot will be
driven to the design depth depending on where you are located
relative to the section line.
Logging Tap to log coverage to be able to see on your map where you have
been dependent on your implement width. A shape file will also be
created with cut/fill and height information.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 469
