Water Management functionality 18 Operations
Control Explanation
Survey
Tap to open the Survey screen where you can survey the section line
you will design.
Design
Tap to open the Design screen where you can select a section line
and then edit the design.
Note –
A white cross displays on the Run screen to show both the
horizontal and vertical location.
Mode
ll Autoslope: Creates sloped tile or surface drainage targeting the
optimal depth defined on the Design tab.
l Slope:Creates consistently sloped tile or surface drainage. From
the starting point, the vehicle leves at a constant slope,
regardless of direction.
ll
Constant Depth: Use to collect a live, rolling survey of the
ground surface. This survey is passed in real time to the control
system, which enables it to run at the specified depth above or
below the ground surface.
The constant depth mode can only be accessed when you have
properly configured manual guidance, Autopilot or EZ-Pilot.
Run depth is defined by setting the Height Offset value to the
desired depth. Examples:
ll For a consistent depth of 4.0' (1.22 m), adjust the Height
Offset to -4.0' (-1.22m).
l For a consistent height of 6" (0.15 m) above the ground
surface, adjust the Height Offset to 6"(0.15cm).
This mode requires two RTK-enabled receivers are available and
assigned on the system. One of the RTK-enabled receivers:
ll Is not required to be an internal receiver
l Must be assigned to the appropriate guidance
plugin/feature
l Must be mounted in front of the antenna used for WM-
Drain
Pipe
ll Pipe Type:Select the type of pipe to be installed.
l Pipe Size:The size of the pipe to be installed.
Slope Increase Increase the design slope by the
Slope Adjust
increment.
Slope Decrease Decrease the design slope by the
Slope Adjust
increment.
