19 Diagnostics Field-IQ diagnostics
Message That Displays Explanation Possible Causes / Actions
FM-1000 integrated display
does not understand the
fault code that was
received from the rate and
section control module.
Probably due to
incompatible firmware
versions.
integrated display and the rate and
section control module.
Report this fault to Trimble Support.
The second pressure entry
must differ from the first
Please enter a different
pressure
The pressure calibration
process requires calibration
at two different pressures.
This message indicates that
you entered the same
pressure twice.
Note –
Zero is a valid
pressure for calibration.
No pressure change has
been detected Please
change the system
pressure
The pressure calibration
process requires calibration
at two different pressures.
This message indicates that
the report from the
pressure sensor did not
change when the second
reading was taken.
The pressure in the system must be
changed between readings, for
example, by either:
l Opening or closing a valve
l Starting or stopping the pump.
If this message persists after the
pressure is changed, check the
installation and wiring of the pressure
sensor.
Invalid setup for flow
calibration
Check:
l Total Nozzles in the Boom tab in
the Field-IQ system setup
l Width in the Hardware tab in
Field-IQ Setup
l Flow meter number
Invalid setup for granular
calibration
Check:
l Shaft Encoder Constant
l Width in the Hardware tab in
Field-IQ Setup
The second gate height The gate height calibration
