3 Basic settings Basic system settings
External lightbar
To set up the external lightbar:
1. Connect the LB25 lightbar to port B on the back of the FM-1000 integrated display.
2. At the Display Setup screen, tap Lightbar.
3. Tap Setup. The Lightbar Configuration screen displays.
4. Tap Lightbar and tap Setup.
5.
Complete the settings as appropriate.
Setting Explanation
Name Name and serial number of the lightbar
Orientation Choose the orientation of the lightbar
Brightness Setting for how bright the lightbar displays
LED Spacing
The distance represented by each LED on the lightbar.
a. Tap the appropriate number field.
b. Enter the required values.
Default: 3 cm per LED/1" per LED
Lightbar Purpose
Choose the purpose of the lightbar
Look ahead time
The distance ahead of the vehicle that the lightbar will use
for LED guidance and offline distance.
Default:0 seconds
Version 9.25, Revision B FM-1000 Integrated Display User Guide 65
