3 Basic settings Basic system settings
Status Item Explanation
Correction Age Length of time since the last correction was received
Correction Type Correction type that is being used
Coverage Percent Percentage of the field area that is covered area
Current Flow Current flow of material
Cut/Fill Difference between the Blade Height and the Target Height:
l When Cut is shown, the current ground height is above the
target height. The height adjustment indicator shows a red
down arrow, which means that the blade needs to move down
to reach the Target Height.
l When Fill is shown, the current ground height is below the
target height. The height adjustment indicator shows a red up
arrow, which means that the blade needs to move up to reach
the Target Height.
Design Height Height the blade will attempt to reach. This is the Design Height ±
the Offset. When the blade reaches the Target Height, the arrows
turn green.
Design Slope When using the Autoslope leveling model, this displays the design
slope with respect to the current location along the section line.
Dist to Feature Distance to the nearest feature
Dist to Pause Distance to the pause position
East Distance that the vehicle is to the east of the field origin point (a
negative number means the vehicle is to the west of the field origin
point)
Engaged Time Length of time that the system has been engaged
Event Coverage Area Area that has been logged during the current event
Event Coverage Distance Distance covered while logging during the current event
Event Coverage Time Length of time that coverage logging has been engaged during the
current event
Event Name Name of the current event
Farm Name Name of the current farm
Field Area Field area within a pivot or headland boundary
Version 9.25, Revision B FM-1000 Integrated Display User Guide 73
