3 Basic settings Basic system settings
Status Item Explanation
Steering Angle Angle reported by the rotary potentiomenter or the AutoSense™
device
Survey Area Total area of the current survey
Survey Cut/Fill Difference between the Blade Height and the Target Height:
l When Cut is shown, the current ground height is above the
target height. The height adjustment indicator shows a red
down arrow, which means that the blade needs to move down
to reach the Target Height.
l When Fill is shown, the current ground height is below the
target height. The height adjustment indicator shows a red up
arrow, which means that the blade needs to move up to reach
the Target Height.
Survey Points Number of survey points that have been created
Swath Length Length of the current guidance line
Note –
FreeForm™ curves are made up of line segments, so the Swath
Length value is not appropriate for FreeForm curves.
Swath Number Swath number (L = left, R = right)
Note –
FreeForm curves are made up of line segments, so the Swath
Number value is not appropriate for FreeForm curves.
Swath Points The number of points that define the current line.
Tank Level Current level of the tank
Tank Level N Level of nitrogen currently in the tank
Tank Level NH3 Level of anhydrous ammonia currently in the tank
Tank/Bin Level Current level of the tank or bin
Target Rate Application target rate
Total Boundaries Area Total area between the current boundaries
Total Seed Rate Total seed rate that is currently being applied
Total Vol Applied Total volume of material applied
Total Vol Applied N Total volume of nitrogen applied
Total Vol Applied NH3 Total volume of anhydrous ammonia applied
Transfer Status Connected Farm™ transfer activity
Version 9.25, Revision B FM-1000 Integrated Display User Guide 81
