Xerox VersaLink B7030 Service Manual

April 2017
2-81
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-151B, 012-152B
Status Indicator RAPs
Launch Issue
012-151B, 012-152B Compiler Exit Sensor Jam RAP
BSD-ON: BSD 13.7 Office Finisher LX Transportation
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-151 Compiler Exit Sensor Off
Jam Entry RAP or the 012-152 Compiler Exit Sensor On Jam Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• (012-152 Only) Ensure that the chute assembly, PL 13.35 Item 16 is installed correctly.
• Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330 code 012-150. Actuate the compiler exit sensor, PL 13.35 Item 10. The display
changes.
YN
Check the wiring between J8869 pin 2 and P/J8988 pin 5 for an open or short circuit, or
a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8988 pins 4 and 6 on the finisher PWB. The voltage is
approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between P/J8988 pin 5 on the finisher PWB and ground. Actuate
the compiler exit sensor.
The voltage changes.
YN
Install a new compiler exit sensor, PL 13.35 Item 10.
Install a new finisher PWB, PL 13.45 Item 2.
Enter dC330 012-038. The transport motor runs.
YN
Check the wiring between P/J8879 on the transport motor and P/J8983 on the finisher
PWB for an open or short circuit, or a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the resistance of the transport motor between P/J8879 pin 1, 2, 5 and 6. The
resistance is approximately 20 Ohms.
YN
Install a new transport motor, PL 13.08 Item 13.
Install a new finisher PWB, PL 13.45 Item 2. If the fault persists, install a new transport
motor, PL 13.08 Item 13.
Check the components that follow:
• The exit roller, paddle shaft and eject belt for wear, damage or contamination, PL 13.29.
• The compiler exit sensor and transport motor circuits for an intermittent condition.
If the fault persists, install a new finisher PWB, PL 13.45 Item 2.
A
A
B
B
