Xerox VersaLink B7030 Service Manual

April 2017
2-82
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-161B
Launch Issue
Status Indicator RAPs
012-161B Set Eject Jam RAP
BSD-ON:BSD 13.10 Office Finisher LX Tamping and Offset (2 of 2)
BSD-ON: BSD 13.13 Office Finisher LX Eject Control (1 of 2)
Procedure
NOTE: Ensure the correct RAP is performed, refer to the 012-161 Set Eject Jam Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Enter dC330 012-151. Actuate the compiler tray no paper sensor, PL 13.28 Item 9. The dis-
play changes.
YN
Check the wiring between J8880 pin 2 and P/J8994 pin 2 on the finisher PWB for an
open or short circuit, or a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8994 pins 1 and 3 on the finisher PWB. The voltage is
approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between P/J8994 pin 2 on the finisher PWB and ground. Actuate the
compiler tray no paper sensor.
The voltage changes.
YN
Install a new compiler tray no paper sensor, PL 13.28 Item 9.
Install a new finisher PWB, PL 13.45 Item 2.
Enter dC330 code 012-055. The eject motor runs.
YN
Check the wiring between P/J8878 on the eject motor and P/J8983 on the finisher PWB
for an open or short circuit, or a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the resistance of the eject motor between P/J8878 pins 1, 3, 4 and 6. The
resistance is approximately 20 Ohms.
YN
Install a new eject motor, PL 13.27 Item 4.
Install a new eject motor, PL 13.27 Item 4. If the fault persists, install a new finisher PWB,
PL 13.45 Item 2.
Check the components that follow:
• The exit roller, entrance roller, paddle shaft and eject belt for wear, damage or contamina-
tion, PL 13.29.
• The compiler tray no paper sensor and eject motor circuits for an intermittent condition.
If the fault persists, install a new finisher PWB, PL 13.45 Item 2.
A
A
