Xerox VersaLink B7030 Service Manual

April 2017
6-56
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
Launch Issue
General Procedures and Information
013-024 Booklet Front Stapler
Motor Forward
Runs the front booklet staple motor
(MOT13-024) forward.
On/off.
013-025 Booklet Front Stapler
Motor Reverse
Runs the front booklet staple motor
(MOT13-024) in reverse.
On/off.
013-026 Booklet Rear Stapler
Motor Forward
Runs the rear booklet staple motor
(MOT13-026) forward.
On/off.
013-027 Booklet Front Stapler
Motor Reverse
Runs the rear booklet staple motor
(MOT13-026) in reverse.
On/off.
013-028 Booklet Staple Move
Motor In
Runs the booklet staple move motor
(MOT13-028) to move booklet sta
-
pler to the I/B side.
On/off. 350 pulses
013-029 Booklet Staple Move
Motor Out
Runs the booklet staple move motor
(MOT13-028) to move booklet sta
-
pler to the O/B side.
On/off. 350 pulses
Table 10 Output Codes 042
Code Displayed Name Description General
042-001 Drum Motor (175 mm/s) Runs the drum motor (MOT42-001)
at 175mm/s (30/35ppm process
speed).
On/off
042-002 Drum Motor (126 mm/s) Runs the drum motor (MOT42-001)
at 126mm/s (25ppm process speed)
On/off
042-003 Main Motor (175 mm/s) Runs the main motor (MOT42-003)
at 175mm/s (30/35ppm process
speed).
On/off
042-004 Main Motor (126 mm/s) Runs the main motor (MOT42-003)
at 126mm/s (25ppm process
speed).
On/off
042-050 Fusing Unit Exhaust
Fan High Speed
Rotation
Runs the fuser exhaust fan (MOT42-
050) at high speed.
On/off
042-051 Fusing Unit Exhaust
Fan Low Speed
Rotation
Runs the fuser exhaust fan (MOT42-
050) at low speed.
On/off
042-052 Marking Fan High
Speed Rotation
Runs the marking fan (MOT42-052)
at high speed.
On/off
042-053 Marking Fan Low Speed
Rotation
Runs the marking fan (MOT42-052)
at low speed.
On/off
Table 11 Output Codes 061 and 062
Code Displayed Name Description General
061-001 LPH forced ON (all-
solid)
Switches on the print head assembly
(all beta pattern).
On/off
Table 9 Output Codes 012 and 013 - Office Finisher LX
Code Displayed Name Description General
061-002 LPH forced ON (Cin
50%)
Switches on the print head assembly
(Cin 50%).
On/off
061-003 LPH forced ON (thyris-
tor transfer)
Switches on the print head assembly
(performs thyristor transfer only.
On/off
062-002 IIT Exposure Lamp Switches on the exposure Lamp. 3
minute timeout.
On/off
062-005 IIT Scan Motor (Scan
direction)
Runs the scan motor (MOT62-005)
to drive the scan carriage 50mm (2
inches) in the scan direction.
-
062-006 IIT Scan Motor (Return
direction)
Runs the scan motor (MOT62-005)
to drive the scan carriage 50mm (2
inches) in the return direction.
-
Table 12 Output Codes 071 to 078
Code Displayed Name Description General
071-001 #1 Feed Motor 1-2-
phase Feed Direction
Runs the tray 1 feed/lift motor
(MOT71-001) at paper feed speed in
the feed direction.
On/off
071-002 #1 Feed Motor 2-phase
Lift Up Direction
Runs the tray 1 feed/lift motor
(MOT71-001) at tray lift speed in the
lift direction.
On/off
072-001 #2 Feed Motor 2-phase
(CW 2) Feed Direction
Runs the tray 2 feed/lift motor
(MOT72-001) at paper feed speed in
the feed direction (2 phase control).
On/off
072-002 #2 Feed Motor 2-phase
(CCW 2) Lift Up Direc
-
tion
Runs the tray 2 feed/lift motor
(MOT72-001) at tray lift speed in the
lift direction.
On/off
072-003 #2 Feed Motor 1-2-
phase (CW 1-2) Feed
Direction
Runs the tray 2 feed/lift motor
(MOT72-001) at paper feed speed in
the feed direction (1-2 phase con
-
trol)
On/off
073-001 #3 Feed Motor 2-phase
(CW 2) Feed Direction
Runs the tray 3 feed/lift motor
(MOT73-001) at paper feed speed in
the feed direction (2 phase control).
On/off
073-002 #3 Feed Motor 2-phase
(CCW 2) Lift Up Direc
-
tion
Runs the tray 3 feed/lift motor
(MOT73-001) at paper feed speed in
the feed direction (1-2 phase con
-
trol)
On/off
073-003 #3 Feed Motor 1-2-
phase (CW 1-2) Feed
Direction
Runs the tray 3 feed/lift motor
(MOT73-001) (1-2 phase control)
On/off
074-001 #4 Feed Motor 2-phase
(CW 2) Feed Direction
Runs the tray 4 feed/lift motor
(MOT74-001) at paper feed speed in
the feed direction (2 phase control).
On/off
Table 11 Output Codes 061 and 062
Code Displayed Name Description General
