Xerox VersaLink B7030 Service Manual

April 2017
6-57
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC330
General Procedures and Information
Launch Issue
074-002 #4 Feed Motor 2-phase
(CCW 2) Lift Up Direc
-
tion
Runs the tray 4 feed/lift motor
(MOT74-001) at tray lift speed in the
lift direction.
On/off
074-003 #4 Feed Motor 1-2-
phase (CW 1-2) Feed
Direction
Runs the tray 4 feed/lift motor
(MOT74 -001) at paper feed speed
in the feed direction (1-2 phase con
-
trol)
On/off
075-001 MSI Feed Clutch Energizes the bypass tray feed
clutch (CL75-001).
On/off
077-001 Takeaway Clutch Energizes the takeaway clutch
(CL077-001).
On/off
077-002 Regi Clutch Energizes the registration clutch
(CL77-002).
On/off
077-003 Duplex Clutch Energizes the duplex clutch (CL77-
003).
On/off
077-004 Exit Gate Solenoid Energizes the exit gate solenoid
(SOL77-004).
On/off
077-010 #1 Exit Offset Solenoid Energizes the exit 1 offset solenoid
(SOL77-010).
On/off
077-014 Exit 2 Drive Motor For-
ward Rotation
Runs the exit 2 drive motor (MOT77-
014) forwards (output direction).
On/off
077-015 Exit 2 Drive Motor
Reverse Rotation
Runs the exit 2 drive motor (MOT77-
014) in reverse (intake direction).
On/off
077-030 TM Feed Ready Signal
Output
Switches on the feed ready signal. On/off
077-031 IOT Regi Stop Signal
Output
Switches on the registration stop
signal.
On/off
077-032 IOT Feed ON Signal
Output
Switches on the feed on signal. On/off
077-033 TM T/A Motor 1 Full
Speed
Runs the TM T/A motor 1 (MOT77-
033) at full speed.
On/off
077-034 TM T/A Motor 1 Half
Speed
Runs the TM T/A motor 1 (MOT77-
033) at half speed.
On/off
077-035 TM T/A Motor 2 Full
Speed
Runs the TM T/A motor 2 (MOT77-
035) at full speed.
On/off
077-036 TM T/A Motor 2 Half
Speed
Runs the TM T/A motor 2 (MOT77-
035) at half speed.
On/off
078-003 HCF1 Feed Motor -
Feed Direction
Runs the HCF feed/lift motor
(MOT78-003) in the feed direction.
On/off
078-004 HCF1 Feed Motor - Lift
Up
Runs the HCF feed/lift motor
(MOT78-003) in the lift direction.
On/off
078-093 HCF1 T/A Motor Runs the HCF T/A motor (MOT78-
093) at low speed.
On/off
078-094 HCF1 T/A Motor Runs the HCF T/A motor (MOT78-
093) at high speed.
On/off
Table 12 Output Codes 071 to 078
Code Displayed Name Description General
Table 13 Output Codes 091 to 094
Code Displayed Name Description General
091-001 BCR AC Bias Energizes the BCR AC bias voltage
at nominal drive level.
On/off
091-002 BCR DC Bias Energizes the BCR DC bias voltage. On/off
091-003 BCR AC/DC Bias Simultaneously energizes the BCR
AC bias and DC bias voltages.
On/off
091-004 BCR AC/DC Bias +
Deve DC Bias
Simultaneously energizes the BCR
AC bias, DC bias and Dev. DC bias
voltages.
On/off
091-005 BCR AC/DC Bias +
Deve DC Bias + Drum
Motor
Simultaneously energizes the BCR
AC bias, DC bias and Dev. DC bias
voltages. Also runs the drive motor
(MOT42-001).
On/off
093-001 DISPENSE MOTOR-K Runs the dispense motor (MOT93-
001) at process speed.
On/off
093-002 DEVE BIAS-DC-K Energizes the Dev. DC bias voltage. On/off
094-001 BTR (+) Energizes the BTR (+) bias. On/off
094-002 BTR (-) Energizes the BTR (-) bias (-1270V). On/off
094-003 DTS Energizes the DTS bias (-2.13kV). On/off
