Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
Launch Issue
Wiring Data
P/J8884 Figure 32 10 Office finisher LX
J8885 Figure 30 7 Office Finisher LX
J8886 Figure 30 6 Office Finisher LX
J8887 Figure 30 5 Office Finisher LX
P/J8888 Figure 32 9 Office finisher LX
J8889 Figure 31 3 Office finisher LX
J8890 Figure 31 4 Office finisher LX
J8891 Figure 32 2 Office finisher LX
P/J8892 Figure 33 1 Booklet maker
P/J8893 Figure 33 2 Booklet maker
J8894 Figure 34 3 Booklet maker
J8895 Figure 34 3 Booklet maker
P/J8896 Figure 33 7 Booklet maker
J8897 Figure 33 4 Booklet maker
J8898 Figure 33 5 Booklet maker
J8899 Figure 33 6 Booklet maker
J8900 Figure 33 8 Booklet maker
J8901 Figure 33 3 Booklet maker
P8903 Figure 32 1 Office finisher LX
P/J8903 Figure 30 2 Office Finisher LX
J8904 Figure 30 3 Office Finisher LX
P/J8905 Figure 30 4 Office Finisher LX
P/J8906 Figure 34 2 Booklet maker
J8980 Figure 31 19 Office finisher LX
P/J8981 Figure 31 10 Office finisher LX
J8982 Figure 31 18 Office finisher LX
P/J8983 Figure 31 9 Office finisher LX
J8984 Figure 31 6 Office finisher LX
J8985 Figure 34 4 Booklet maker
P8985 Figure 31 17 Office finisher LX
P/J8986 Figure 31 8 Office finisher LX
J8987 Figure 29 3 Horizontal transport
P8987 Figure 31 16 Office finisher LX
P/J8988 Figure 31 11 Office finisher LX
J8989 Figure 31 13 Office finisher LX
P/J8990 Figure 31 12 Office finisher LX
P/J8991 Figure 34 9 Booklet maker
P/J8992 Figure 34 7 Booklet maker
P/J8993 Figure 34 6 Booklet maker
P/J8994 Figure 34 5 Booklet maker
P/J8995 Figure 34 8 Booklet maker
Table 7 Connectors 8800 to 8995
P/J No Figure No. Item No. PJ Location
Table 8 Connectors F10 to USB
P/J No Figure No. Item No. PJ Location
F10 Figure 7 3 Thermostat center
F10 Figure 7 4 Thermostat front
FS001 Figure 35 3 HCF
FS002 Figure 35 3 HCF
FS003 Figure 35 8 HCF
FS004 Figure 35 8 HCF
K(K) Figure 6 1 Print head assembly
LINE2 Figure 25 8 Line 2 fax PWB (option)
LINE3 Figure 25 9 Line 3 fax PWB (option)
MJ1 Figure 25 7 Line 1 fax PWB (LINE)
MJ2 Figure 25 6 Line 1 fax PWB (TEL)
T1 Figure 2 16 Terminal
T1 Figure 14 14 Terminal
T2 Figure 2 15 Terminal
T2 Figure 14 15 Terminal
T3 Figure 2 13 Terminal
T4 Figure 2 14 Terminal
USB Figure 4 4 USB
