April 2017
7-7
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
Wiring Data
Launch Issue
P/J757 Figure 2 1 DADF PWB
DP800 Figure 14 9 Connector
J800 Figure 35 11 HCF
P/J1332 Figure 10 24 ESS PWB
P/J1334 Figure 10 15 ESS PWB
P/J1352 Figure 10 2 ESS PWB
P/J1363 Figure 10 16 ESS PWB
P/J1365 Figure 10 9 ESS PWB
P/J7001 Figure 3 5 Lamp assembly
P/J7251 Figure 3 2 Platen close sensor
P/J7252 Figure 3 1 Platen angle sensor
P/J7253 Figure 3 4 IIT registration sensor
P/J7254 Figure 3 8 APS sensor 1
P/J7255 Figure 3 10 APS sensor 3
Table 6 Connectors 8700 to 8799
P/J No Figure No. Item No. PJ Location
P/J8700 Figure 27 2 Integrated office finisher
P/J8701 Figure 27 1 Integrated office finisher
P/J8702 Figure 27 11 Integrated office finisher
P/J8703 Figure 27 10 Integrated office finisher
P/J8704 Figure 27 13 Integrated office finisher
P/J8705 Figure 27 12 Integrated office finisher
P/J8706 Figure 27 8 Integrated office finisher
P/J8707 Figure 27 3 Integrated office finisher
P/J8708 Figure 27 17 Integrated office finisher
P/J8709 Figure 27 16 Integrated office finisher
P/J8710 Figure 27 9 Integrated office finisher
P/J8711 Figure 27 4 Integrated office finisher
P/J8721 Figure 28 2 Integrated office finisher
P/J8722 Figure 28 1 Integrated office finisher
P/J8723 Figure 28 6 Integrated office finisher
P/J8724 Figure 26 1 Integrated office finisher
P/J8725 Figure 28 11 Integrated office finisher
P/J8726 Figure 26 7 Integrated office finisher
P/J8727 Figure 26 9 Integrated office finisher
P/J8728 Figure 26 8 Integrated office finisher
P/J8729 Figure 26 6 Integrated office finisher
P/J8730 Figure 26 2 Integrated office finisher
P/J8731 Figure 26 4 Integrated office finisher
Table 5 Connectors 600 to 7254
P/J No Figure No. Item No. PJ Location
P/J8732 Figure 26 3 Integrated office finisher
P/J8733 Figure 27 14 Integrated office finisher
P/J8734 Figure 27 15 Integrated office finisher
P/J8735 Figure 26 5 Integrated office finisher
P/J8736 Figure 28 5 Integrated office finisher
J8737 Figure 28 9 Integrated office finisher
J8738 Figure 28 10 Integrated office finisher
P/J8739 Figure 27 7 Integrated office finisher
P/J8740 Figure 27 5 Integrated office finisher
P/J8741 Figure 27 6 Integrated office finisher
J8742A Figure 28 7 Integrated office finisher
J8742B Figure 28 8 Integrated office finisher
Table 7 Connectors 8800 to 8995
P/J No Figure No. Item No. PJ Location
J8860 Figure 29 1 Horizontal transport
J8861 Figure 29 4 Horizontal transport
P/J8862 Figure 29 2 Horizontal transport
J8863 Figure 29 7 Horizontal transport
P8863 Figure 29 5 Horizontal transport
J8864 Figure 29 8 Horizontal transport
J8865 Figure 29 10 Horizontal transport
J8866 Figure 29 6 Horizontal transport
P/J8867 Figure 29 9 Horizontal transport
J8868 Figure 32 4 Office finisher LX
J8869 Figure 32 3 Office finisher LX
J8870 Figure 31 24 Office finisher LX
J8871 Figure 31 23 Office finisher LX
J8872 Figure 31 21 Office finisher LX
J8873 Figure 31 2 Office finisher LX
J8874 Figure 31 1 Office finisher LX
J8875 Figure 31 22 Office finisher LX
P/J8876 Figure 32 5 Office finisher LX
P/J8877 Figure 31 20 Office finisher LX
P/J8878 Figure 31 7 Office finisher LX
P/J8879 Figure 31 5 Office finisher LX
J8880 Figure 32 7 Office finisher LX
J8881 Figure 32 11 Office finisher LX
J8882 Figure 32 6 Office finisher LX
P/J8883 Figure 32 8 Office finisher LX
Table 6 Connectors 8700 to 8799
P/J No Figure No. Item No. PJ Location
