7-6
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
Launch Issue
Wiring Data
P/J541 Figure 22 1 TTM PWB
P/J545 Figure 19 6 1TM PWB
J545 Figure 21 6 3TM PWB
P/J545 Figure 22 5 TTM PWB
P548 Figure 19 9 1TM PWB
P/J548 Figure 17 3 STM PWB
P/J548 Figure 21 9 3TM PWB
P/J548 Figure 22 7 TTM PWB
P/J549 Figure 19 8 1TM PWB
P/J549 Figure 21 8 3TM PWB
P/J549 Figure 22 6 TTM PWB
P/J550 Figure 17 6 STM PWB
P/J550 Figure 19 4 1TM PWB
P/J550 Figure 21 4 3TM PWB
P/J550 Figure 22 2 TTM PWB
P/J551 Figure 17 5 STM PWB
P/J551 Figure 19 5 1TM PWB
P/J551 Figure 21 5 3TM PWB
P/J551 Figure 22 3 TTM PWB
P/J552 Figure 22 4 TTM PWB
P553 Figure 17 7 STM PWB (to CPU-ROM writer)
P553 Figure 19 7 1TM PWB (to CPU-ROM writer)
P/J553 Figure 21 7 3TM PWB (to CPU-ROM writer)
P/J567 Figure 7 5 Fuser fuse PWB
P/J590 Figure 11 18 Drive PWB
P/J590 Figure 31 15 Office finisher LX
P/J591 Figure 11 19 Drive PWB
P/J591 Figure 31 14 Office finisher LX
J592 Figure 19 1 Connector (1TM)
J592 Figure 21 1 Connector (3TM)
P/J592 Figure 11 17 Drive PWB
P/J593 Figure 11 20 Drive PWB
P/J594 Figure 11 21 Drive PWB
Table 5 Connectors 600 to 7254
P/J No Figure No. Item No. PJ Location
P/J600 Figure 13 5 Connector (7 pin)
P/J601 Figure 13 4 Connector (2 pin)
P/J602 Figure 8 6 Connector (3 pin)
P/J603 Figure 8 3 Connector (5 pin)
Table 4 Connectors 400 to 594
P/J No Figure No. Item No. PJ Location
P/J604 Figure 9 5 Connector (9 pin)
P/J605 Figure 9 6 Connector (4 pin)
P/J606 Figure 13 8 Connector (4 pin)
DP612 Figure 7 1 Fuser
DJ614 Figure 6 2 Drum cartridge
DP614A Figure 6 5 Connector
DP614B Figure 6 6 Connector
P/J614 Figure 13 11 Connector (3 pin)
P/J661 Figure 16 6 Connector (4 pin) (STM)
P/J661 Figure 18 8 Connector (4 pin) (1TM)
P/J661 Figure 20 14 Connector (4 pin) (3TM)
P/J661 Figure 23 6 Connector (4 pin) (TTM)
P/J662 Figure 20 12 Connector (4 pin) (3TM)
P/J662 Figure 23 9 Connector (4 pin) (TTM)
P/J663 Figure 20 10 Connector (4 pin) (3TM)
P/J663 Figure 22 8 Connector (4 pin) (TTM)
P/J668 Figure 18 7 Connector (2 pin) (1TM)
P/J668 Figure 20 9 Connector (2 pin) (3TM)
P/J668 Figure 23 10 Connector (2 pin) (TTM)
P/J669 Figure 16 7 Connector (9 pin) (STM)
P/J669 Figure 18 9 Connector (9 pin) (1TM)
P/J669 Figure 20 15 Connector (9 pin) (3TM)
P/J669 Figure 23 6 Connector (9 pin) (TTM)
P/J671 Figure 20 13 Connector (9 pin) (3TM)
P/J671 Figure 23 8 Connector (9 pin) (TTM)
P/J673 Figure 20 11 Connector (9 pin) (3TM)
P/J673 Figure 22 1 Connector (9 pin) (TTM)
P/J674 Figure 22 9 Connector (3 pin) (TTM)
P/J675 Figure 18 10 Connector (3 pin) (1TM)
P/J675 Figure 20 16 Connector (3 pin) (3TM)
P/J675 Figure 23 5 Connector (3 pin) (TTM)
J678 Figure 35 10 HCF
J690 Figure 17 1 Connector (STM)
P/J700 Figure 3 7 CCD assembly
P/J750 Figure 10 4 ESS PWB
P/J751 Figure 2 7 DADF PWB
P/J752 Figure 2 4 DADF PWB
P/J753 Figure 2 5 DADF PWB
P/J754 Figure 2 6 DADF PWB (option)
P/J755 Figure 2 3 DADF PWB
P/J756 Figure 2 2 DADF PWB
Table 5 Connectors 600 to 7254
P/J No Figure No. Item No. PJ Location
