Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
Wiring Data
Launch Issue
P/J204 Figure 13 10 Exit 1 OCT solenoid
P/J205 Figure 8 4 Bypass tray feed clutch
P/J206 Figure 8 5 Duplex clutch
P/J207 Figure 14 8 Take away clutch
P/J209 Figure 6 4 Connector (4 pin)
P/J210 Figure 2 9 DADF feed motor
P/J210 Figure 14 1 Fuser exhaust fan
P/J211 Figure 9 7 Tray 1 feed/lift up motor
P/J212 Figure 14 7 Main motor
P/J213 Figure 14 5 Drum motor
P/J217 Figure 5 1 Toner dispense motor
P/J218 Figure 13 7 Exit 2 motor
P/J220 Figure 3 6 IIT scan motor
P/J221 Figure 14 6 Main motor
P/J221 Figure 16 1 Tray 2 feed/lift up motor (STM)
P/J221 Figure 18 1 Tray 2 feed/lift up motor (1TM)
P/J221 Figure 20 1 Tray 2 feed/lift up motor (3TM)
P/J221 Figure 23 1 Tray 2 feed/lift up motor (TTM)
P/J222 Figure 14 4 Drum motor
P/J222 Figure 20 1 Tray 3 feed/lift up motor (3TM)
P/J222 Figure 23 1 Tray 3 feed/lift up motor (TTM)
P/J223 Figure 20 1 Tray 4 feed/lift up motor (3TM)
P/J223 Figure 23 1 Tray 4 feed/lift up motor (TTM)
P/J224 Figure 17 2 STM takeaway motor
P/J224 Figure 19 2 1TM takeaway motor
P/J224 Figure 21 2 3TM takeaway motor
P/J224 Figure 22 13 TTM takeaway motor 1
P/J226 Figure 22 12 TTM takeaway motor 2
P/J300 Figure 10 14 ESS PWB
P/J302 Figure 10 20 ESS PWB
P/J310 Figure 10 19 ESS PWB
P/J311 Figure 10 10 ESS PWB
P/J315 Figure 10 23 ESS PWB
P/J340 Figure 10 21 ESS PWB
P/J343 Figure 10 12 ESS PWB
P/J345 Figure 10 3 ESS PWB
J346 Figure 10 1 ESS PWB
P/J351 Figure 10 17 ESS PWB
P/J352 Figure 25 4 Line 1 fax PWB
P/J353 Figure 25 3 Line 1 fax PWB
P/J355 Figure 25 2 Line 1 fax PWB/riser PWB (option)
Table 3 Connectors 200 to 384
P/J No Figure No. Item No. PJ Location
P/J356 Figure 25 5 Fax speaker
P/J363 Figure 25 10 Line 2 fax PWB/riser PWB (option)
P/J364 Figure 25 1 Line 3 fax PWB/riser PWB (option)
P/J380 Figure 10 18 ESS PWB
P/J384 Figure 10 13 ESS PWB
Table 4 Connectors 400 to 594
P/J No Figure No. Item No. PJ Location
P/J400 Figure 11 4 Drive PWB
P/J401 Figure 11 1 Drive PWB
P/J402 Figure 11 10 Drive PWB
P/J403 Figure 11 11 Drive PWB
P/J404 Figure 11 14 Drive PWB
P/J405 Figure 11 6 Drive PWB
P/J406 Figure 11 5 Drive PWB
P/J407 Figure 11 9 Drive PWB
P/J409 Figure 11 24 Drive PWB
P/J410 Figure 11 13 Drive PWB
P/J411 Figure 11 3 Drive PWB
P/J413 Figure 11 7 Drive PWB
P/J414 Figure 11 22 Drive PWB
P/J416 Figure 11 8 Drive PWB
P/J417 Figure 11 15 Drive PWB
P/J418 Figure 11 16 Drive PWB
P/J419 Figure 11 2 Drive PWB
P/J420 Figure 10 6 ESS PWB
P/J421 Figure 10 5 ESS PWB
P/J422 Figure 10 8 ESS PWB
P/J422 Figure 11 12 Drive PWB
P/J423 Figure 10 7 ESS PWB
P/J425 Figure 11 23 Drive PWB
P/J501 Figure 12 9 LVPS
P/J502 Figure 12 11 LVPS
P/J504 Figure 12 7 LVPS
P/J505 Figure 12 2 LVPS
P/J506 Figure 12 1 LVPS
P/J520 Figure 5 2 HVPS
P/J541 Figure 17 4 STM PWB
P/J541 Figure 19 3 1TM PWB
P/J541 Figure 21 3 3TM PWB
Table 3 Connectors 200 to 384
P/J No Figure No. Item No. PJ Location
