Xerox VersaLink B7030 Service Manual

April 2017
2-95
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-302B , 012-303
Status Indicator RAPs
Launch Issue
012-302B Front Cover Interlock Open RAP
BSD-ON: BSD 13.3 Office Finisher LX Interlock Switching
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-302 Front Cover Interlock Open
Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the installation of the front door interlock switch, PL 13.45 Item 19.
• Check that the front cover can be opened and closed.
Procedure
Enter dC330 code 012-302. Open then close the finisher front cover to actuate the front door
interlock switch.
The display changes.
YN
Cheat the front door interlock switch. The display changes.
YN
Check the wiring between J8982 pin 3 and J8891 pin 2B, and from J8891 pin 2A to
J8982 pin 2 for an open or short circuit, or a loose or damaged connector.
The wir-
ing is good.
YN
Reconnect or repair as necessary.
Remove the cheater. Measure the voltage between J8891 pin 2A on the front door
interlock switch and ground.
The voltage is approximately +5VDC.
YN
Check the wiring from J8891 pin 2A to J8982 pin 3 for an open or short circuit,
or a loose or damaged connector. If the wires are good, install a new finisher
PWB, PL 13.45 Item 2.
Cheat the interlock switch. The voltage drops to 0VDC.
YN
Install a new front door interlock switch, PL 13.45 Item 19.
Install a new finisher PWB, PL 13.45 Item 2.
Check the actuator for damage or misalignment
Check the interlock circuit for an intermittent condition. If the fault persists, install a new finisher
PWB, PL 13.45 Item 2.
012-303 Finisher horizontal Transport Cover Open RAP
BSD-ON: BSD 13.5 Office Finisher LX Horizontal Transport
012-303 The finisher horizontal transport cover is open.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the installation of the horizontal transport open sensor, PL 13.08 Item 3.
• Check that the finisher horizontal transport cover can be opened and closed
Procedure
Enter dC330 code 012-303. Actuate the horizontal transport open sensor. The display
changes.
YN
Check the wiring between J8860 pin 2 and J8897 pin 2 for an open or short circuit, or a
loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between J8897 pins 3 and 1 on the finisher PWB. The voltage is
approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between J8897 pin 2 on the finisher PWB and ground. Actuate the
horizontal transport open sensor.
The voltage changes.
YN
Install a new horizontal transport open sensor, PL 13.08 Item 3.
Install a new finisher PWB, PL 13.45 Item 2.
If the fault persists, install a new finisher PWB, PL 13.45 Item 2.

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
