April 2017
2-96
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-334B, 012-901
Launch Issue
Status Indicator RAPs
012-334B Download Fail RAP
BSD-ON: BSD 3.6 PWB Communications (ESS PWB/Drive PWB to Finisher)
Procedure
NOTE: Ensure the correct RAP is performed, refer to the 012-334 Download Fail Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Check the wiring between the finisher and the IOT.
2. Reload the software, GP 4
3. If the fault persists, install a new finisher PWB, PL 13.45 Item 2.
012-901 Horizontal Transport Entrance Sensor Static Jam
RAP
012-901 Paper remains on the horizontal transport entrance sensor.
Procedure
Perform the 012-111 to 012-131 Horizontal Transport Entrance Sensor Jam RAP.
