Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only I – 9
Index
T
Technical support, 1-2
Temperature Sensor
operation, 2-42
Test print
black 20% ESS, 5-46
cmy 20% ESS, 5-47
color registration, 6-3
contamination check, 5-49
cyan 20% ESS, 5-45
engine, MFP, 4-50
engine, SFP, 4-47
gradation ESS, 5-47
grid 2 ESS, 5-44
magenta 20% ESS, 5-45
no image IOT, 5-43
pattern IOT, 5-44
printing, 4-17
repeating defects, 5-50
toner pallet check, 5-48
yellow 20% ESS, 5-46
Test Prints, 5-43 to 5-50
Texture, A-14
Thermistor, 2-18
Toner Cartridge, 2-8
components, 2-34
CRUM, 2-34
life count, 6-10
location, 2-34
operation, 2-7
part number, 9-24
removal, 8-12
Toner Cartridge Holder
part number, 9-24
removal, 8-107
Toner Cartridges, MFP, 1-9
Toner Door Switch, 2-42
part number, 9-24
removal, MFP, 8-150
removal, SFP, 8-135
Toner Door, MFP
location, 1-5
part number, 9-10
removal, 8-42
Toner Door, SFP
location, 1-4
part number, 9-6
removal, 8-21
Toner motor
operation, 2-7
testing, 4-31
Top Cover removal, MFP, 8-45
Top Cover, SFP
part number, 9-6
removal, 8-15
Transfer Belt, 2-10
ADC Sensor, 2-31
life count, 6-10
location, MFP, 1-9
location, SFP, 1-8
operation, 2-9
part number, 9-26
pivot kit
part number, 9-26
removal, 8-109
removal, 8-112
waste toner reservoir, 2-13
Transfer Belt Pivot Kit
part number, 9-26
removal, 8-109
Transport
drive, 2-14
path, 2-15
sensors, 2-19
Tray, 2-20
bottom plate, 2-20
components, 2-20
end guide, 2-20
location, 1-4, 1-5
part number, 9-14
side guides, 2-20
Tray 1, 1-4
no paper sensor
testing, 4-21
Tray 2
drive clutch
testing, 4-46
Feed Gear Kit
part number, 9-54
feed motor
part number, 9-54
removal, 8-177
testing, 4-44
feed roller
part number, 9-58
removal, 8-182
feed solenoid
removal, 8-176
testing, 4-45
feeder operation, 2-24
harness
part number, 9-56
removal, 8-179
location, 1-4
no paper sensor
part number, 9-58
removal, 8-186
testing, 4-42
paper path sensor
removal, 8-187
testing, 4-43
part number, 9-52, 9-60
registration input actuator
part number, 9-58
registration sensor
part number, 9-58
removal, 8-187
removal, 8-167
separator holder
part number, 9-60
removal, 8-190

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
