Xerox WorkCentre 6505 Service Manual

I – 8 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Index
Reports
Email Address Book List, A-12
Error History, A-7
Job History, A-6
Print Volume, A-8
Protocol Monitor, A-11
Server Address List, A-13
Reset password, 1-12
Resolution
copy, 1-19
fax, 1-20
print, 1-17
scanning, 1-18
Right Front Holder
removal, 8-26
Right Imaging Unit Restraint Block
part number, 9-22
removal, 8-94
Right Side Cover
removal, MFP, 8-40
removal, SFP, 8-17
Right Side Cover, SFP
part number, 9-6
Right Side Door Switch
location, 2-19
S
Scanner
Counter Balance Kit
part number, 9-45
Scanner Assembly
operation, 2-60, 2-61
Scanner Diagnostic Testing Procedures, 4-58
Scanner Lamp, 4-63
Scanner Parameter Setting, 6-11
Scanner, laser, 2-33
Scanning
Document Glass, 2-64
Specifications, 1-18
scanning
ADF, 2-65
Sensor, 2-17
ADC, 2-31
ADF, 2-19
ADF Cover, 4-62
ADF Feed, 4-61
ADF Tray, 4-60
color mode switching, 2-36
Exit, 2-31
humidity, 2-42
part number, MFP, 9-34
part number, SFP, 9-32
location, 2-19
manual feed no paper, 2-27
microswitch, 2-18
no paper, part number, 9-19
Optional Feeder paper path, 2-24
photo-receptive, 2-17
photo-reflective, 2-17
registration
manual feed operation, 2-27
part number, 9-19
Scanner Home Position, 4-59
temperature, 2-42
thermistor, 2-18
Tray 2 no paper, 2-24
tray no paper, 2-22
types, 2-17
Separator Holder
part number, 9-14
removal, 8-6
Separator Roller
location, 2-20
operation, 2-21
Serial number, 9-2
format, 9-2
location, 9-2
Server Address List, A-13
Service checklist, 3-4
Service Diagnostics
entering and exiting, 4-8
menu maps, 4-9
printer test descriptions, 4-12
test print generation, 5-43
using, 4-7
Shaft Kit
part number, MFP, 9-12
part number, SFP, 9-8
Side Switch - see Toner Door Switch
Skew
measurement, 5-52
troubleshooting, 5-32
Specifications
Copy, 1-19
electrical, 1-21
environmental, 1-22
Fax, 1-20
image, 5-51
media, 1-28
Memory, 1-21
mounting surface, 1-27
noise, 1-22
printing, 1-17
Scanning, 1-18
Spots, troubleshooting, 5-25
Startup Page, A-5
Sub Drive Assembly, 2-36
location, 2-36
operation, 2-49
part number, 9-28
removal, 8-113
testing, 4-30
System configuration, MFP, 2-63
System startup, 4-5

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
