1.3 Servo Drive and Corresponding Servo Motor
1.3.1 220V Series
Motor Servo Drive
Motor
series
Power
Output
(W)
Model Number
Rated
Current
(Arms)
Max.
Instantaneous
current
(A)
Model Number
Continuous
Output
Current
(Arms)
Max.
Instantaneous
output current
(A)
Low Inertia
ECMA-C 3000 r/min
Single-
/Three-
phase
50
ECMA-C1040F□S 0.69 2.05
ASD-A2-0121-□ 0.90 2.70
100
ECMA-C△0401□S
0.90 2.70
200
ECMA-C△0602□S
1.55 4.65
ASD-A2-0221-□ 1.55 4.65
400
ECMA-C△0604□S
2.60 7.80
ASD-A2-0421-□ 2.60 7.80
400
ECMA-C△0804□7
2.60 7.80
750
ECMA-C△0807□S
5.10 15.30
ASD-A2-0721-□ 5.10 15.30
750
ECMA-C△0907□S
3.66 11.00
1000
ECMA-C△0910□S
4.25 12.37
ASD-A2-1021-□ 7.30 21.90
1000
ECMA-C△1010□S
7.30 21.90
2000
ECMA-C△1020□S
12.05 36.15
ASD-A2-2023-□ 13.40 40.20
3000
ECMA-C△1330□4
17.2 47.5
ASD-A2-3023-□ 19.40 58.20
Medium Inertia
ECMA-E 2000 r/min
Single-
/Three-
phase
500
ECMA-E△1305□S
2.90 8.70
ASD-A2-0421-□ 2.60 7.80
1000
ECMA-E△1310□S
5.60 16.80
ASD-A2-1021-□ 7.30 21.90
1500
ECMA-E△1315□S
8.30 24.90
ASD-A2-1521-□ 8.30 24.90
2000
ECMA-E△1320□S
11.01 33.03
ASD-A2-2023-□ 13.40 40.20
2000
ECMA-E△1820□S
11.22 33.66
3000
ECMA-E△1830□S
16.10 48.30
ASD-A2-3023-□ 19.40 58.20
3500
ECMA-E△1835□S
19.20 57.60
Medium-high inertia
ECMA-F 1500 r/min
Single-
/Three-
phase
500
ECMA-F△1305□S
3.90 12.10
ASD-A2-0721-□ 5.10 15.30
850
ECMA-F△1308□S
7.10 19.40
ASD-A2-1021-□ 7.30 21.90
1300
ECMA-F△1313□S
12.60 38.60
ASD-A2-2023-□ 13.40 40.20
1800
ECMA-F△1318□S
13.00 36.00
3000
ECMA-F△1830□S
19.40 58.20
ASD-A2-3023-□ 19.40 58.20
4500
ECMA-F△1845□S
32.50 81.30
ASD-A2-4523-□ 32.50 - -
5500 ECMA-
△
F 1855□3 40.00 100.00 ASD-A2-5523-□ 40.00 - -
7500 ECMA-
△
F 1875□3 47.50 118.80 ASD-A2-7523-□ 47.50 - -
11000 ECMA-F1221B□3 51.80 129.50 ASD-A2-1B23-□ 54.40 - -
15000 ECMA-F1221F□S 61.50 145.70 ASD-A2-1F23-□ 70.00 - -
