Chapter 8 Parameters
ASD
A-A2
8-278
Revision February, 2017
P7-27
PDAT63
PATH# 63 Data
Address: 0736H
0737H
Operational
Interface
：
Panel / Software
Communication
Related Section:
7.10
Default
：
0
Control
Mode
：
PR
Unit
：
-
Range
：
-2147483648 ~ +2147483647
Data Size
：
32-bit
Format
：
Decimal
Settings
：
Please refer to the description of P6-03.
