Delta ASDA-A2 User Manual

ASDA-A2 Chapter 8 Parameters
Revision February, 2017 8-287
Setting Value: 0x45
DI Name Function Description of Digital Input (DI)
Trigger
Method
Control
Mode
INHP In position mode, when this DI is ON, the external pulse input
command is not working.
(Note: The function has to be set to DI8 so as to ensure the
instantaneity of pulse prohibition)
Level
triggered
PT
Setting Value: 0x46
DI Name Function Description of Digital Input (DI)
Trigger
Method
Control
Mode
STOP Motor stops Rising
edge
triggered
PR
Setting Value: 0x47
DI Name Function Description of Digital Input (DI)
Trigger
Method
Control
Mode
PFQS
This DI can be used to stop the emergency stop of deceleration
time. The setting of deceleration time is identical to P5-03. When
DI.PFQS is on, AL35F will occur. Then, motor starts to
decelerate. When the speed reaches 0, AL3CF occurs and servo
is off. Please turn on DI.ARST to servo on the drive again.
Rising
edge
triggered
PT,PR,T,S
NOTE
1）11 ~ 17 Single control modes; 18~20 Dual control mode.
2）When P2-10 ~ P2-17 is set to 0, DI has no function.
