ASD
A-A2
Chapter 12 Absolute S
ystem
12-4
Revision February, 2017
12.1.2 Battery Box Dimensions
Single Battery Box
Delta Model Number: ASD-MDBT0100
Units: mm
Weight
44 g
Dual Battery Box
Delta Model Number: ASD-MDBT0200
Units: mm
Weight
80 g
