Delta ASDA-A2 User Manual

ASDA-A2 Chapter 11 Specifications
11-14 Revision February, 2017
ECMA Series
F△ 13
F△ 18
F122
05
08
13
18
30
45
55
75
1B
1F
Brake pull-in time
[ms (Max)]
70
70
70
70
70
70
70
70
70
70
Vibration grade (μm)
15
Operating temperature (
o
C)
0
o
C to 40
o
C
Storage temperature (
o
C)
-10
o
C to 80
o
C
Operating humidity
20% to 90% RH (non-condensing)
Storage humidity
20% to 90% RH (non-condensing)
Vibration capacity
2.5 G
IP Rating
IP65 (use the waterproof connector and shaft seal installation (or oil seal) model)
Approvals
Note:
*1 The rated torque is the continuous permissible torque between 0~40˚C operating temperature
which is suitable for the following heat sink dimension.
ECMA-__04 / 06 / 08 : 250 mm x 250 mm x 6 mm
ECMA-__10 : 300 mm x 300 mm x 12 mm
ECMA-__13 : 400 mm x 400 mm x 20 mm
ECMA-__18 : 550 mm x 550 mm x 30 mm
ECMA-__22 : 650 mm x 650 mm x 35 mm
Material: Aluminum – F40, F60, F80, F100, F130, F180, F220
*2 The built-in brake of the servo motor is for remaining the item in stop status. Do not use it to decelerate
or as the dynamic brake.
3 If desire to reach the max. torque limit of motor 250%, it is suggest to use the servo drive with higher
watt.
