Delta ASDA-A2 User Manual

ASDA-A2 Chapter 11 Specifications
11-24 Revision February, 2017
ECMA Series
L△ 13
M△ 13
05
08
13
09
Operating humidity
20 ~ 90%RH (non-condensing)
Storage humidity
20 ~ 90%RH (non-condensing)
Vibration capacity
2.5 G
IP Rating
IP65 (use the waterproof connector and shaft seal installation (or oil
seal) model)
Approvals
Note:
*1 The rated torque is the continuous permissible torque between 0~40˚C operating temperature which is
suitable for the following heat sink dimension.
ECMA-_ _ 08：250 mm x 250 mm x 6 mm
ECMA-_ _ 13：400 mm x 400 mm x 20 mm
ECMA-_ _ 18：550 mm x 550 mm x 30 mm
ECMA-_ _ 22：650 mm x 650 mm x 35 mm
Material type: Aluminum –F80, F130, F180, F220
*2 The built-in brake of the servo motor is for remaining the item in stop status. Do not use it to decelerate or
as the dynamic brake.
3 Model of ECMA-L11308 is applying for UL approval.

Delta ASDA-A2 Specifications

General

Control Mode	Position, Speed, Torque
Model	ASDA-A2 Series
Operating Voltage	200 ~ 230VAC / 380 ~ 480VAC
Power Supply	200-230VAC ±10%, single-phase
Communication Interface	RS-485, CANopen
Feedback	Incremental encoder, Absolute encoder
Protection	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	0°C
Storage Temperature	-20°C
Humidity	20% to 90% RH (non-condensing)
Position Control Mode Features	Electronic Cam
Weight	Varies depending on the model. Please refer to the specific model's datasheet.
