Delta ASDA-A2 User Manual

ASDA-A2 Chapter 12 Absolute System
12-22 Revision February, 2017
⑯
. If there doesn’t have any error occurred during communication course for the host controller to
finish bit 0 to bit 79 (80 bits data), the functions of DI4, DO2, DO3 will be changed back to their
original functions before communication cycle started.
NOTE
If ABSW does not go back to high level signal after the changing of ABSE for signal low to high
that is a sign of error occurring, there must be some other errors existing. Please check if the
coordinate data still there, the voltage level of battery, or overflowing on the coordinate value.
A new communication cycle can be started only all of these errors been removed.

Delta ASDA-A2 Specifications

General

Control Mode	Position, Speed, Torque
Model	ASDA-A2 Series
Operating Voltage	200 ~ 230VAC / 380 ~ 480VAC
Power Supply	200-230VAC ±10%, single-phase
Communication Interface	RS-485, CANopen
Feedback	Incremental encoder, Absolute encoder
Protection	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	0°C
Storage Temperature	-20°C
Humidity	20% to 90% RH (non-condensing)
Position Control Mode Features	Electronic Cam
Weight	Varies depending on the model. Please refer to the specific model's datasheet.
