211-05-98A Steering Column Switches 211-05-98A
DIAGNOSIS AND TESTING
Steering Column Switches
Inspection and Verification
1. Verify the customer concern.
2. Visually inspect for obvious signs of damage.
Refer to the following chart:
Visual Inspection Chart
Mechanical
Electrical
• Ignition switch.
• Battery.
• Fuse.
• Wiring.
• Connector(s).
3. If inspection reveals an obvious cause, rectify
this before continuing. If the concern
remains, proceed to the Symptom Chart.
4. Additional information on connectors is
available.
Refer to the relevant wiring diagrams,
Symptom Chart
Symptom Chart
Condition
Possible Sources
Action
• The ignition switch is inoperative
• Switch.
• Circuit.
• Fuse.
• GO to Pinpoint Test A.
• No power in ACC
• Switch.
• Circuit.
• GO to Pinpoint Test B.
• No power in RUN
• Switch.
• Circuit.
• Relay.
• GO to Pinpoint Test C.
• No power in START
• Switch.
• Circuit(s).
• Relay.
• GO to Pinpoint Test D.
• The multifunction switch hazard
warning switch does not operate
correctly
• Fuse(s).
• Circuit.
• Switch.
• GO to Pinpoint Test E.
