303-01B-65 Engine — 1.6L / 1.3L RoCam 303-01B-65
IN-VEHICLE REPAIR (CONTINUED)
E6640 EN 07/2001 2002 Bantam
18. Remove the oil level indicator tube retaining
bolt.
19. NOTE:
Secure the timing chain to a wire
hook to prevent it from falling down into the
cylinder block.
Using the special tool, remove the camshaft
sprocket.
20. Place a trolley jack with a wooden block
under the oil pan and raise slowly until the
engine front mounting is free from strain.
21. Remove the intake manifold.
22. Remove the engine front mounting bracket.
