303-04D-11 Fuel Charging and Controls — 1.8L Diesel Engine 303-04D-11
REMOVAL AND INSTALLATION (CONTINUED)
E6448 EN 09/2001 2002 Bantam
8. Remove the crankshaft pulley/vibration
damper.
9. Remove the timing belt lower cover
retaining bolts.
10. Lower the vehicle.
Vehicles with power steering
11. Loosen the power steering pump pulley
retaining bolts.
12. De-tension the accessory drive belt.
1. Loosen the Allen bolt.
2. De-tension the belt.
13. Remove the accessory drive belt.
To Next Page
