Freescale Semiconductor MPC5604B - Page 398

MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 387
Table 21-4. Checksum bits configuration
CFD CCD LINCFR Checksum sent
1 1 Read/Write None
1 0 Read-only None
0 1 Read/Write Programmed in LINCFR by bits CF[0:7]
0 0 Read-only Hardware calculated
Table 21-5. LIN master break length selection
MBL Length
0000 10-bit
0001 11-bit
0010 12-bit
0011 13-bit
0100 14-bit
0101 15-bit
0110 16-bit
0111 17-bit
1000 18-bit
1001 19-bit
1010 20-bit
1011 21-bit
1100 22-bit
1101 23-bit
1110 36-bit
1111 50-bit
Table 21-6. Operating mode selection
SLEEP INIT Operating mode
1 0 Sleep (reset value)
x 1 Initialization
00Normal
