MPC5604B/C Microcontroller Reference Manual, Rev. 8
Freescale Semiconductor 399
21.7.1.11 LIN integer baud rate register (LINIBRR)
Table 21-15. LINFBRR field descriptions
Field Description
DIV_F Fraction bits of LFDIV
The 4 fraction bits define the value of the fraction of the LINFlex divider (LFDIV).
Fraction (LFDIV) = Decimal value of DIV_F / 16.
This field can be written in Initialization mode only.
Offset: 0x0028 Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R 000
DIV_M
W
Reset0000000000000000
Figure 21-16. LIN integer baud rate register (LINIBRR)
Table 21-16. LINIBRR field descriptions
Field Description
DIV_M LFDIV mantissa
This field defines the LINFlex divider (LFDIV) mantissa value (see Table 21-17). This field can be
written in Initialization mode only.
Table 21-17. Integer baud rate selection
DIV_M[0:12] Mantissa
0x0000 LIN clock disabled
0x0001 1
... ...
0x1FFE 8190
ox1FFF 8191
