Fujitsu PRIMERGY RX2540 M2

RX2540 M2 Upgrade and Maintenance Manual 487
Front panel and external front connectors
For Installations with LTO drive
Figure 364: Lock and screw for installations with LTO drive
1 Lock 2 screw to fasten the front panel cage
when a LTO drive is installed.
