4 Using the Data
14-42 WindO/I-NV4 User’s Manual
10
Select the specification method for the amount of data to copy in Number of Data.
■ Value
Use a constant.
Specifies the amount to copy (1 to 64).
■ Device Address
Use a word device.
Specifies the source device address. You can only specify an internal device.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
11
Select the order to copy data in Stored Order of Data.
■ From Newest to Oldest
Of the data to copy, copies from the start point in order of the newest data first.
■ From Oldest to Newest
Of the data to copy, copies from the start point in order of the oldest data first.
12
Select the data to copy from the data in Target Data.
Select the Sampling Time check box to copy the sampling time data from the data.
Select the Value of Device Address check box to copy the value of device address from the data. When not copying
the value of device address, proceed to step
16
.
13
Select the specification method for the data number to copy the value in Data Number.
■ Value
Use a constant.
■ Device Address
Use a word device.
14
Specify the data number of the data to start copying out of the data to copy with Start Number.
If you select Value, specify the data number (1 to 128).
If you select Device Address, specify the source device address. You can only specify an internal device. Click to
display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address
Settings” on page 2-70.
When the Sampling Time check box is selected, the data number is 1. This cannot be changed.
15
Specify the data number of the data to end copying out of the data to copy with End Number.
If you select Value, specify the data number (1 to 128).
If you select Device Address, specify the source device address. You can only specify an internal device. Click to
display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address
Settings” on page 2-70.
16
Select the condition to start copying in Trigger Condition.
■ Always
Copies each time the data is updated.
■ Device Address
Specifies the device address that triggers the start of copying the data. Copies the data when the value of the
specified device address changes from 0 to 1. Click to display the Tag Editor. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-70.
17
Click OK to close the Individual Settings dialog box.
You are returned to the Data Log Settings dialog box.
The maximum amount of data that can be copied to the internal device is 64.
