2 Setting and Monitoring the Printer
32-2 WindO/I-NV4 User’s Manual
2.1 Setting the Printer
When printing, specify printer settings such as; paper size and ink color on the Printer tab of the Project Settings
dialog box.
For details, refer to Chapter 4 “3.8 Printer Tab” on page 4-62.
2.2 Monitoring the Printer
To monitor the status of the printer, use the System Area.
For details, refer to Chapter 4 “System Area 2” on page 4-32.
■ Printer busy
When the printer is printing, bit 3 at the system area address number +3 will turn ON.
■ Printer timeout error
If an error occurs while the printer is printing, bit 9 at the system area address number +2 will turn ON.
2 Setting and Monitoring the Printer
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
• If the printer does not support the paper size selected on the Printer tab in the Project Settings dialog
box, printing is performed with the paper size selected in the printer's settings.
When the edge of the data is not printed, enable No Trimming and Bordered in the printer's settings.
The color cannot be configured. To print in monochrome, configure the print color on the printer that is
used.
• When connecting the MICRO/I to a printer, an error may occur on the printer side as an unsupported
device, but data is sent that satisfies the PictBridge standard when printing, so it can be printed correctly.
