8 Selector Switch

8-146 WindO/I-NV4 User’s Manual

8.1 How the Selector Switch is Used

Writes a 0 or 1 to a bit device. This is an exclusive control that only writes a single value as 1 and all other values as 0.

• Switching between two Run Modes (Manual and Auto)

• Switching between three Run Modes (Filling - Stop - Discharge)

8 Selector Switch

HG3G

HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T

HG4G HG1G HG1P

HG2J-7U

Automatic

Manual

Automatic

Auto Manual

Auto Manual Auto Manual

R-button

Ch2

Ch1

L-button

Knob

Press L-button to

switch to Auto.

Press R-button to

switch to Manual.

Operate

manually

FSD

R-button

Ch3Ch2Ch1

L-button

Knob

Press L-button to

switch to Filling.

Switch to Stop

(the operation differs according

to the switch type)

Press R-button to

switch to Discharge.
