WindO/I-NV4 User’s Manual 4-65
3 Project Settings Dialog Box
4
Project Settings
3.11 Expansion Module Tab
The Expansion Module tab is used to configure input and output expansion modules attached to the MICRO/I. For
details on expansion modules, refer to Chapter 30 “Expansion Modules” on page 30-1.
■ Use Cyclic Script
A Cyclic Script is a script with a trigger condition that is a fixed interval (10 ms increments). When a script is specified
as a Cyclic Script, it executes at the specified fixed interval independent of the scan time of the screen (processing
time for parts on the screen).
Select this check box to use a Cyclic Script. Only one Cyclic Script can be configured for the project.
■ Script ID
Specify the script ID to use (1 to 32000) as the Cyclic Script.
Click to display Script Manager. Select a script from the script list. For details, refer to Chapter 20 “2.2 Script
Manager” on page 20-7.
■ Script Name
Displays the name of the script specified with Script ID.
■ Execution Interval
Specifies the interval to execute the script as 10 to 1000 (10 ms increments).
■ Module Configuration
*1
Displays the Module Configuration dialog box. For details, refer to Chapter 30 “5 Module Configuration Dialog Box”
on page 30-30.
*1 HG5G/4G/3G/2G-V only
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P HG2J-7U
