WindO/I-NV4 User’s Manual 34-13
3 Settings
34
MICRO/I Setup
3.6 File Manager
File Manager manages files stored on SD memory cards, USB flash drives, and MICRO/I internal memory.
It can format external memory devices, copy and delete files, and run associated applications.
To return to the Main Menu screen, press Main Menu at the top of the screen.
• Format
Select the drive you want to format, and then press FORMAT.
• Copy
Select the file you want to copy, and then press COPY.
If USB Flash Drive or SD Memory Card is selected as the source and the destination device, the selected file will be
copied to the device. If the source or the destination device is MICRO/I, “Project Data Transfer” function will be
executed and MICRO/I project will be downloaded or uploaded. If the source or the destination device is PLC, “PLC
Program Data Transfer” function will be executed and PLC Program will be downloaded or uploaded. (Refer to
Chapter 29 “1 Project Transfer Function” on page 29-1.)
• Delete
Select the files you want to delete, and then press DEL.
3.7 Ext.Mem.Device
From the Main Menu screen, press (Ext.Mem.Device), and then (Format) to format the USB flash drive.
To return to the Main Menu screen, press (Main Menu) at the top of the screen.
3.8 Top Page
Press Top Page (Top Page) in the Main Menu screen to return to the Top Page.
3.9 Self Diagnosis (Self Diag.)
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
If the external memory device is not recognized correctly, press RELOAD to reload it.
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
• You need inspection jigs to run self-diagnosis.
• Self Diagnosis is a special screen for factory inspections. Please do not use it during the operation.
