WindO/I-NV4 User’s Manual 30-29
4 Cyclic Script
30
Expansion Modules
A Cyclic Script is a script whose trigger condition can be set to a fixed interval (in increments of 10 milliseconds). Only
one Cyclic Script can be assigned to the project.
When a script is specified as a Cyclic Script, it executes at the specified fixed intervals independent of the scan time of
the screen (processing time for parts on the screen).
4.1 Setting Procedures for Cyclic Script
Follow these steps to program a Cyclic Script.
1 On the Configuration tab, in the System Setup group, click Project.
The Project Settings dialog box appears.
2 On the Expansion Module tab, select the Use Cyclic Script check box.
3 Specify the Script ID and Execution Interval.
■ Script ID
Specify the script ID to use (from 1 to 32000) as the Cyclic Script.
■ Execution Interval(x 10msec)
Specify the interval at which the script should execute from 1 to 100 (10 milliseconds increments).
The specified script will execute at the specified intervals.
4 Click OK.
4 Cyclic Script
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P HG2J-7U
