WindO/I-NV4 User’s Manual 30-25
3 Analog I/O Modules
30
Expansion Modules
3.3 Device Allocation
● Analog Input Module
Allocation of device address for the analog input module is shown below.
For details about the parameter setting values, refer to “ Analog Input Parameter Setting Values” on page 30-25.
Analog Input Parameter Setting Values
The parameter setting values are as follows.
■ Signal Type
Channel
Parameter R/W
FC6A-J2C1
FC6A-J2C4
FC6A-J4A1
FC6A-J4A4
FC6A-J8A1
FC6A-J8A4
FC6A-J4CN1
FC6A-J4CN4
FC6A-J4CH1Y
FC6A-J4CH4Y
FC6A-J8CU1
FC6A-J8CU4
No.
Address
Number
Address
Number
Address
Number
Address
Number
Address
Number
Address
Number
CH0
Analog input data R +0 +0 +0 +0 +0 +0
Analog input status R +1 +1 +1 +1 +1 +1
CH1
Analog input data R +2 +2 +2 +2 +2 +2
Analog input status R +3 +3 +3 +3 +3 +3
CH2
Analog input data R ― +4 +4 +4 +4 +4
Analog input status R ― +5 +5 +5 +5 +5
CH3
Analog input data R ― +6 +6 +6 +6 +6
Analog input status R ― +7 +7 +7 +7 +7
CH4
Analog input data R ― ― +8 ― ― +8
Analog input status R ― ― +9 ― ― +9
CH5
Analog input data R ― ― +10 ― ― +10
Analog input status R ― ― +11 ― ― +11
CH6
Analog input data R ― ― +12 ― ― +12
Analog input status R ― ― +13 ― ― +13
CH7
Analog input data R ― ― +14 ― ― +14
Analog input status R ― ― +15 ― ― +15
Setting Value Signal Type
0 Unused
1 0 to 10V DC
2 -10 to +10V DC
3 0 to 20mA DC
4 4 to 20mA DC
5 Type K thermocouple
6 Type J thermocouple
7 Type R thermocouple
8 Type S thermocouple
9 Type B thermocouple
10 Type E thermocouple
11 Type T thermocouple
12 Type N thermocouple
13 Type C thermocouple
14 Pt100
15 Pt1000
16 Ni100
