1 HG2J-7U

35-6 WindO/I-NV4 User’s Manual

1.6 Dimensions

Unit: mm

Depending on the type of connection cable used the dimensions shown above will change.

The dimensions given here are representative values and are intended for reference only.

186.0

128.0

176.2

6.024.4

28.3

118.2

56 176.2

15 118.2
