IDEC WindO/I-NV4

5 Password Input Screen
5-28 WindO/I-NV4 User’s Manual
5.2 Password Input Screen Configuration
■ Title Bar
Displays buttons and the title of the Password Input Screen.
■ (Move) Button
Moves the Password Input Screen.
■ (Close) Button
Closes the Password Input Screen.
■ Screen Display Area
The area where drawing objects and parts are placed.
Close ButtonMove Button
Title Bar
Screen Display Area
When there is a title bar on the Password Input Screen, touch switches that are within 20 dots of the title
bar will not respond.
1
Press
2
Touch the position where the
screen will be moved to
3
The screen will move the position
that was touched
MICRO/I MICRO/I MICRO/I
The location that was touched will
become the location of
.
• The Password Input Screen can be moved in the range where the button can be displayed.
• The Password Input Screen will be moved in units of 1 dot.
