WindO/I-NV4 User’s Manual 35-49

3 HG4G/3G, HG2G-5F

MICRO/I Specifications

3.9 USB Cable Lock Pin Attachment

When using the USB device, attach the USB Cable Lock Pin to prevent disconnecting the USB cable from the HG4G/3G,

HG2G-5F.

1 Insert the USB cable into the USB2 port.

2 Strain the [Edge part] of the USB Cable Lock Pin, and insert the [Edge part] to the 2 holes upper the USB2 port.

3 Fasten the USB Clamp Band around the USB cable and the [Clamp part], secure them tightly.

Clamp part

Edge part

HG4G/3G HG2G-5F

Upper Holes

HG4G/3G

HG2G-5F

Fasten the USB Clamp Band without the space between the [Clamp part] and it, and the inclination.

NG NG

With a gap

Slanted
