WindO/I-NV4 User’s Manual 24-27
4 Clear
24
Online Function
4.2 Deleting Data from an External Memory Device Inserted in the MICRO/I
1 Change communication settings according to the connection method between the computer and the MICRO/I.
In the Communication Settings dialog box, select Operator Interface from Communicate with. For details, refer
to “1.3 Change Communication Settings” on page 24-5.
2 Open project data.
3 On the Online tab, in the MICRO/I group, click Clear, then click Stored Data in External Memory Device.
The Clear Data dialog box is displayed.
4 Select the check box for the data items to be deleted from the External Memory Device folder.
Screenshot, Alarm Log files, Data Log files, Operation Log files, and Recipe Files
5 Click OK.
• When Communicate with is set to Operator Interface and Port to USB
*1
, deletion of the data starts.
• When Communicate with is set to Operator Interface and Port is set to Ethernet, the Target IP Address
dialog box is displayed. Specify the IP address of the MICRO/I, and then click OK to start deletion of the data. For
details, refer to “To execute a function other than the project data download” on page 24-10.
6 Click Yes.
7 Click Close.
This concludes clearing data on the external memory device.
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
If security is enabled in the MICRO/I project, the Password Screen is displayed. Enter the password. For
details, refer to Chapter 23 “User Accounts and the Security Function” on page 23-1.
