WindO/I-NV4 User’s Manual 18-17
4 Creating and Deleting Data for Recipes
18
Recipe Function
4.2 Creating Recipe Files
Recipe files can be created on the external memory device
*1
with the following procedure. The recipe values
configured on the Data tab in the Individual Settings dialog box are saved in recipe files.
“Creating Recipe Files in the Recipe Settings Dialog Box” on page 18-17
“Creating Recipe Files when Downloading Project Data” on page 18-19
“Creating Recipe Files with a Text Editor” on page 18-20
●
Creating Recipe Files in the Recipe Settings Dialog Box
1 Insert an external memory device in the computer.
Insert an external memory device
*1
into the USB port or memory card slot of your computer, or via a docking station,
etc.
2 On the Configuration tab, in the System Setup group, click Recipe.
The Recipe Settings dialog box is displayed.
3 Click Save Recipe Files to External Memory Device.
The Select Drive dialog box is displayed.
*1 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F,
USB flash drive for HG2G-5T and HG1G/1P
Computer
Via a docking station etc.
SD memory card
Into SD memory card slot
Into USB port
USB flash drive
SD memory card
USB flash drive
To Next Page
