4 Creating and Deleting Data for Recipes
18-20 WindO/I-NV4 User’s Manual
4 Verify Communication Settings and click Download.
Since the recipe files are downloaded to the external memory device inserted in the MICRO/I, use the same settings
as when communicating with the MICRO/I.
To change Communication Settings, click Change to display the Communication Settings dialog box. Change
Communicate with, Port, and Baud Rate. For details, refer to Chapter 24 “1 Communicating with the MICRO/I”
on page 24-1.
5 Click Yes.
The Download Project dialog box is displayed and the project files start downloading.
When finished downloading, a completion message is displayed.
6 Click OK.
You are returned to the Download Project dialog box.
7 Click Close.
●
Creating Recipe Files with a Text Editor
You can edit recipe files using Notepad, commercially available text editors, or spreadsheet software.
1 Write the data for the amount of data in “value of device address” comma (,) new line order.
If the amount of data in the recipe file is lower than the amount of data for the top device address configured on the
Channel tab in the Individual Settings dialog box, 0 is written in the rest of the device addresses.
2 Save the file with the “.csv” extension.
Give the file the file name configured on the Block tab in the Individual Settings dialog box. If the file name is
different, 0 is written to all the device addresses.
3
Copy the edited recipe files to the “RECIPE” folder in the External Memory Device folder on the external memory device.
If security is enabled in the MICRO/I project, the Password Screen is displayed. Select the user name and
enter the password. For details, refer to Chapter 23 “User Accounts and the Security Function” on page 23-1.
To Next Page
