WindO/I-NV4 User’s Manual 24-29
6 System Information
24
Online Function
Displays information about the system software and downloaded project data of the MICRO/I.
This function can be used to show information about project data during editing and to simultaneously check details
of project data downloaded to the MICRO/I.
6.1 Displaying System Information
1 Change communication settings according to the connection method between the computer and the MICRO/I.
If communicating with a MICRO/I inserted in a computer, in the Communication Settings dialog box, select Operator
Interface from Communicate with. For details, refer to “1.3 Change Communication Settings” on page 24-5.
2 On the Home tab, in the Project group, click Target Info..
• When Communicate with is set to Operator Interface and Port is set to USB
*1
, the System Information
dialog box is displayed.
• When Communicate with is set to Operator Interface and Port is set to Ethernet, the Target IP Address
dialog box is displayed. Specify the IP address of the MICRO/I, and then click OK to display the System Information
dialog box. For details, refer to “To execute a function other than the project data download” on page 24-10.
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
6 System Information
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
While editing project data, information about system software and project data can be displayed even by
clicking Target Info. in the MICRO/I group on the Online tab.
To Next Page
