WindO/I-NV4 User’s Manual 28-17
2 FTP Server Function
28
Maintenance
2.3 Hierarchy of the FTP Server
The hierarchy of the FTP server is as follows:
2.4 Supported Commands and Transfer modes
• Commands defined by RFC959
• Active mode and Passive mode
2.5 Verified FTP Client
With the FTP server function, the operation has been checked by using the following FTP client.
*4
• FFFTP
• FileZilla
• Core FTP Lite
• MICRO/I (FTP client function)
• IDEC PLC (FTP client function)
*1 HG2J-7U, HG5G/4G/3G/2G-V, HG4G/3G , HG2G-5F only
*2 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F
*3 USB flash drive inserted in USB2 for HG2J-7U
*4 HG2J-7U as of December 2021, HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P type as of January 2019
Example:
A
*1
B
HGDATA01
/
(The root folder of the External Memory Device
*2
)
(The root folder of hte FTP server)
(The root folder of the USB flash drive
*3
)
RECIPE
When no external memory device is inserted in the MICRO/I or when no folder is specified to Target, the
root folder of the FTP server is displayed.
SFTP and FTPS are not supported.
To use FileZilla, select the Limit number of simultaneous connections check box on Transfer
Settings tab in Site Manager and set Maximum number of connections to "1" in advance.
• For the settings and how to use the FTP client software, please check the help and manual of each
software.
• Depending on the FTP client software, including subfolders may not be able to write in batch. In this
case, please write data each one level.
To Next Page
